Year: 2015 - 2016 - 2017
Design / Surveying / Permitting
- Marina Master Plan
- Berthing capacity (200 yachts)
- Main Breakwater (Vertical RC perforated Caisson type, L=510m @max -23.00m)
- Secondary Breakwater (Vertical RC perforated Caisson type, L=307m @Max-21.00m)
- Quaywalls (L=422m @-3.00m MSL) / Precast concrete blocks (Gravity QW)
- Quaywalls (L=220m @-6.50m MSL) / Precast concrete blocks (Gravity QW)
- Finger Piers (L=342m @-3.00m MSL, Nbr 4) / Precast concrete elements
- Land reclamation and bituminous / RC Platforms
- RC and bituminous platforms
- Infrastructure (Electrical supply, pipes, manholes, lighting poles)
- Infrastructure (Water supply, Pumps, pipes, manholes, tanks)
- Marina master headquarter, restaurants, offices, shops (4,889m2)
- Fueling station
- Reclaimed area (42,587m2)
- Water body (66,253m2)
- Specifications / Drawings / BoQ / Permitting
